Denon DHT-FS5 Service Manual

52
DHT-FS5
SKA FRONT P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
7100 nsp IR RECEIVER TSOP34138SB1
310421880350
7107 nsp IC SM 74HCT4094D 933715330118
7113 nsp IC SM 74HCT4094D 933715330118
7101 nsp TRA POW SM PBSS5140U 934056513115
7102 nsp TRA POW SM PBSS5140U 934056513115
7103 nsp TRA POW SM PBSS5140U 934056513115
7110 nsp TRA SIG SM BC847B 319801042030
7111 nsp TRA SIG SM BC847B 319801042030
7112 nsp TRA SIG SM BC847B 319801042030
7114 nsp TRA SIG SM BC847B 319801042030
7115 nsp TRA SIG SM BC847B 319801042030
7117 nsp TRA SIG SM BC847B 319801042030
7119 nsp TRA SIG SM BC847B 319801042030
7121 nsp TRA SIG SM BC847B 319801042030
7124 nsp TRA SIG SM BC847B 319801042030
7108 nsp LED DS DA56-11GWA for E3,E2 310413051050
7108 nsp LED DS DA56-11EWA for JP
310413051180
6100 nsp DIO SIG SM BAS316
319801010630
6105 nsp DIO SIG SM BAS316 319801010630
6106 nsp DIO SIG SM BAS316 319801010630
6104 nsp LED VS SM LTST-C190KRK 932218532685
6107 nsp LED VS SM LTST-C190KGK
932218533685
6108 nsp LED VS SM LTST-C190KGK for JP 932218533685
6109 nsp LED VS SM LTST-C190KGK 932218533685
6110 nsp LED VS SM LTST-C190KGK 932218533685
6111 nsp LED VS SM LTST-C190KGK 932218533685
RESISTORS GROUP
3100 nsp RST SM 0805 820R PM5
319802158210
3101 nsp RST SM 0603 10K PM5 319802131030
3102 nsp RST SM 0603 10K PM5 319802131030
3103 nsp RST SM 0603 10K PM5 319802131030
3109 nsp RST SM 0603 2K2 PM5 319802132220
3110 nsp RST SM 0603 2K2 PM5 319802132220
3111 nsp RST SM 0603 2K2 PM5 319802132220
3115 nsp RST SM 0603 4K7 PM5 319802134720
3116 nsp RST SM 0603 10K PM5 319802131030
3117 nsp RST SM 0603 220K PM5 319802132240
3118 nsp RST SM 0603 1K PM5 319802131020
3119 nsp RST SM 0603 22K PM5 319802132230
3121 nsp RST SM 0805 100R PM5 319802151010
3123 nsp RST SM 0805 100R PM5 319802151010
3126 nsp RST SM 0805 100R PM5 319802151010
3129 nsp RST SM 0805 100R PM5 319802151010
3131 nsp RST SM 0603 10R PM5 319802131090
3132 nsp RST SM 0603 10R PM5 319802131090
3133 nsp RST SM 0805 100R PM5 319802151010
3137 nsp RST SM 0805 100R PM5 319802151010

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
