Denon DHT-FS5 Service Manual

53
DHT-FS5
3141 nsp RST SM 0805 100R PM5 319802151010
3144 nsp RST SM 0805 100R PM5 319802151010
3151 nsp RST SM 0603 100R PM5 319802131010
3154 nsp RST SM 0603 3K3 PM5 319802133320
3155 nsp RST SM 0603 3K3 PM5 319802133320
3156 nsp RST SM 0603 3K3 PM5 319802133320
3157 nsp RST SM 0603 3K3 PM5 319802133320
3158 nsp RST SM 0603 3K3 PM5 319802133320
3159 nsp RST SM 0603 3K3 PM5 319802133320
3160 nsp RST SM 0603 3K3 PM5 319802133320
3161 nsp RST SM 0603 3K3 PM5 319802133320
3170 nsp RST SM 0603 220R PM5 319802132210
3171 nsp RST SM 0603 470R PM5 319802134710
3172 nsp RST SM 0603 470R PM5 319802134710
3173 nsp RST SM 0603 470R PM5 319802134710
3174 nsp RST SM 0603 100R PM5 319802131010
CAPACITORS GROUP
2100 nsp CER2 0603 X7R 16V 100N
319801731040
2101 nsp ELCAP SM WZ 10V 220U PM20 202002100316
2102 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2103 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2104 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2105 nsp CER2 0603 X7R 16V 100N 319801731040
2107 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2109 nsp CER1 0603 NP0 50V 100P 319801631010
2110 nsp CER1 0603 NP0 50V 100P 319801631010
2112 nsp CER1 0603 NP0 50V 100P 319801631010
2113 nsp CER1 0603 NP0 50V 100P 319801631010
2114 nsp CER1 0603 NP0 50V 220P 319801632210
2115 nsp CER1 0603 NP0 50V 220P 319801632210
2117 nsp CER2 0603 X7R 16V 100N 319801731040
OTHERS PARTS GROUP
1103 nsp SWI TACT 1P 1POS 12V V 2MM5
242212803093
1107 nsp CON H 9P M 2.00 SM PH R 242202518756
5100 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
5102 nsp IND FXD 0603 EMI 100MHZ 220R 242254900393
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
