Denon DHT-FS5 Service Manual

54
DHT-FS5
SKA CONNECTOR P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
7000 00MYJ15000270 SOC OPT 1P F, TORX147L(F,T)
242203300629
7001 00MYJ15000270 SOC OPT 1P F, TORX147L(F,T) 242203300629
6001 nsp DIO REG SM BZX384-C4V7 319802054780
RESISTORS GROUP
3000 nsp RST SM 0603 100R PM5
319802131010
3001 nsp RST SM 0603 1K0 PM5 319802131020
3002 nsp RST SM 0603 100R PM5 319802131010
3003 nsp RST SM 0603 75R PM5 319802137590
3004 nsp RST SM 0603 100R PM5 319802131010
3005 nsp RST SM 0603 100R PM5 319802131010
3008 nsp RST SM 0603 100R PM5 319802131010
CAPACITORS GROUP
2000 nsp CER2 0603 X7R 50V 10N
319801731030
2002 nsp CER2 0603 X7R 16V 100N 319801731040
2003 nsp CER1 0603 NP0 50V 100P 319801631010
2004 nsp CER2 0603 X7R 16V 100N 319801731040
2005 nsp CER2 0603 X7R 16V 100N 319801731040
2006 nsp CER1 0603 NP0 50V 100P 319801631010
2007 nsp CER1 0603 NP0 50V 100P 319801631010
2008 nsp CER1 0603 NP0 50V 100P 319801631010
2009 nsp CER1 0603 NP0 50V 100P 319801631010
2012 nsp CER2 0603 X7R 50V 10N 319801731030
2013 nsp CER1 0603 NP0 50V 100P 319801631010
2014 nsp CER1 0603 NP0 50V 100P 319801631010
2015 nsp CER2 0603 X7R 16V 100N 319801731040
OTHERS PARTS GROUP
1000 nsp SOC CINCH H 2P F 1L2 WHRD
242202605418
1001 nsp SOC CINCH H 1P F 1L1 BK 310413051161
1002 nsp CON BM V 2P M 2.50 EH 241202000724
1005 nsp CON V 18P F 1.00 FFC 0.3 242202518239
1006 nsp SOC CINCH H 1P F BK 242202604425
1011 nsp SOC PHONE H 1P F 3.5 ST BK 242202605909
5000 nsp IND FXD 0603 EMI 100MHZ 60R 242254945153
5001 nsp IND FXD 0603 EMI 100MHZ 60R 242254945153
s
s

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
