5
DHT-FS5
(2) e5PPH-PHCORD を Plate-Shielding にクランプバンド
で３ヶ所固定する。Foam を２ヶ所貼付け固定する。
(3) rCABLEVH-3L125 を Cover-Rear のリブの 2ヶ所のス
リットに通してワイヤーを整形する。
(4) tCABLEXARR-12L135 を Cover-Rear にクランプバンド
で固定する。
(2) Fasten the 5P PH-PH CORD(e) three times on the
Plate-Shielding with a clamp band, and paste the Foam
twice on.
(3) rPass the CABLE VH-3 L125(r) through twice slits of
rib on the Cover-Rear and arrange the wire.
(4) Fasten the CABLE XARR-12 L135(t) on the Cover-
Rear with the clamp band.
Foam
㽴
④
⑤

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
