Denon HEOS - HEOS Bar Physical Overview and Ports; Front, Bottom, and Back Panel Features

o
Front panel
[Tabletop]
.
qw
[Wall mount]
.
w q
A
Remote control sensor
This receives signals from the remote control unit.
B
Status LED
Please refer to the “Status LED table” for LED color and state meaning. (v
p. 68)
