Dimensions (Unit : in. (mm))
.
5 7/8 (148) 5 7/8 (148)
3 1/2 (88)
2 7/8 (72)
1/2
(11)
1 5/8 (40)
7 1/8
(178)
29 3/8 (745)
7 1/8
(178)
43 3/8 (1100)
o
Weight : 10 lbs 9 oz (4.8 kg)
For the purpose of improvement, the specifications and design are subject to change without notice.
