12
(3) Remove the feed pump plate.
(4) Remove the O-ring and two pins.
NOTE:
O-rings can not be reused.
NOTE:
When removing the O-ring, be careful not to
damage the part's O-ring groove. (Please do
not use sharp metal objects to remove.)
3.5 Removing the Fuel Temperature Sensor
(1) Using a spanner, remove the fuel temperature
sensor.
QD0875
QD1851E
Pin
O-Ring
QD0877
