25
(7) Install the dial gauge on the camshaft clearance
measurer.
(8) Pull the camshaft clearance measurer to set the
dial gauge to 0.
(9) Press the camshaft clearance measurer in to
measure the drive shaft thrust.
• Normal: 0.35 ± 0.2mm
NOTE:
If the measurement does not meet the
standard, replace the washer or cam shaft with
a new one.
QD0077
QD0079
QD0080
To Next Page
