DENT Instruments powerscout 3037 User Manual

40
For system pulse output:
 kWh pulse output—write 44001 into the pulse output configuration object.
 kVAh pulse output—write 44011 into the pulse output configuration object.
 kVARh pulse output—write 44008 into the pulse output configuration object.
MODBUS OUTPUT PORT REGISTERS
Modbus
Register
Offset Register Name Detailed Description
44402 4401/5301
Port 1 output control
when used as an on/off—
open/closed switch
0 = output LOW (closed)
1 = output HIGH (open) [default]
Register 45110 must = 0 to use
45110 5109/5309
Digital Port 1
Configuration
Turns pulses on/off
0 = No pulses, Port may be used as an
on/off—
open/closed switch
44001 = System kWh pulses
44008 = System kVARh pulses
44011 = System kVAh pulses
45111 5110/5310
Port 1 pulse output relay
type
0 = normally open (HIGH)
1 = normally closed (LOW)
Table III-2: Modbus Digital Port Pulse Output
BACNET OUTPUT PORT OBJECTS
Refer to the following two tables to configure the PowerScout output port when using the BACnet
protocol.
Object
Identifier
Object Name Detailed Description
13020
Port 1 output control when used as an
on/off—open/closed switch
0 = output LOW (closed) 1 = output HIGH
(open) [default]
Object 13100 present value must = 0 to use
13100
Digital Port 1 Configuration
Turns pulses on/off
0 = No pulses, Port may be used as an
on/off—
open/closed switch
44001 = System kWh pulses
44008 = System kVARh pulses
44011 = System kVAh pulses
13110 Port 1 pulse output relay type
0 = normally open (HIGH)
1 = normally closed (LOW)
Table III-3: BACnet Digital Port 1 Pulse Output
