56
READ/WRITE REGISTERS—READ/SET OBJECTS
Th
e Read/Write Registers, Read/Set Objects screen provides diagnostic and
special configuration options, allowing the changing or viewing of the value of
any PowerScout register or object. The tab name changes depending on what
protocol (Modbus or BACnet) you are using. Its use is not required for a basic
setup.
1) Enter a register/object address. Refer to the Appendices, All Things
Modbus or BACnet Objects for a list of registers/objects and their
descriptions.
-or-
Click List to select a register/object from the Register/Object Picker dialog
box.
Use the Register/Object Picker dialog box to search for registers/objects
by name. The selected value is entered on the Read/Write Registers—
Read/Set Objects screen.
2) Click Read to see the current value.
3) Enter a new value in the New Value field.
4) Click Write to change to the new value.
5) Click Clear Totals to clear accumulated data.
DID YOU KNOW? Accumulated data is
registers/objects with a time
reference, such as time since reset,
kWh, demands, etc.
