70
Modbus Offset Register
Description
* System=sum of three phases
46058 6057 Amps L3 “
46059 6058 Volts L1 to Neutral Individual Instantaneous Phase to Neutral Voltages
(V)
46060 6059 Volts L2 to Neutral “
46061 6060 Volts L3 to Neutral “
46062 6061 Time Since Reset LSW (Seconds) Seconds since kWh, kVAh, kVARh and associated
Demand registers were reset. LSW (resettable)
46063 6062 Time Since Reset MSW
(Seconds)
Seconds since CAM. MSW
46080 6079 Positive kW System Average Equals Positive KWH_SYSTEM_L&M ÷
(TimeSinceReset_L&M seconds /3600 seconds/Hr)
(resettable)
46081 6080 kW Demand System Minimum Min Average power window (kW)
46082 6081 kVA Demand System Maximum Maximum Instantaneous kVA Demand (kW,
resettable).
46083 6082 kVA Demand System Now System Average kVA Demand for the most recent
(current) Demand Window (resettable).
46084 6083 kVAR Demand System Max System Maximum kVAR Demand (kVAR, resettable). It
displays the default value after a CAM until 1 demand
window elapses. After a power cycle or CPU reset the
value is not reset but it does not update again until 1
demand window elapses.
NEGATIVE POWER/ENERGY MEASUREMENT REGISTERS
Modbus Offset Register
Detailed Description
* System=sum of three phases
47001 7000 Negative kWh System LSW System Negative True Energy LSW (kWh, resettable)
47002 7001 Negative kWh System MSW System Negative True Energy MSW (kWh, resettable)
47003 7002 Negative kW System System Negative Instantaneous Negative True Power
(kW) (net sum of all individual kWs, if sum is positive
