86
Object
Identifier Name
Description
* System=sum of three phases
9120 Displacement PF L3 “
9150 Apparent PF L1 Individual Phase apparent Power Factors (PF)
9180 Apparent PF L2 “
9210 Apparent PF L3 “
10000 Measured Line Frequency Line Frequency (Hz)
10010 Time Since Reset Seconds since accumulator registers were reset.
POSITIVE POWER/ENERGY MEASUREMENT OBJECTS
Object
Identifier
Name
Description
* System=sum of three phases
1080 kW System Average Positive Equals kWh System Positive / (Time Since Reset /3600 seconds/Hr)
(resettable) (Signed Net)
1110 kW System Maximum Positive System Highest Instantaneous Positive Draw Since Reset (kW)
(Signed Net)
1140 kW System Minimum Positive System Lowest Instantaneous Positive Draw Since Reset (kW,
resettable)
2010 kWh System Total Positive System True Energy (kWh) Positive (Signed Net)
2040 kWh L1 Positive
Individual Phase True Energy (kWh) (Signed)
2070 kWh L2 Positive “
2100 kWh L3 Positive “
6010 kVARh System System Total Reactive Energy (Signed Net)
6020 kVARh System Total Positive
System True Energy (kVARh) Positive (Signed Net)
6050 kVARh L1 Positive
Individual Phase Reactive Energy (kVAR) (Signed)
6080 kVARh L2 Positive “
6110 kVARh L3 Positive “
7001 kVAh System Total Positive System Total Positive Apparent Energy (kVAh) (Signed Net)
Accumulates only when kW is positive
7020 kVAh L1 Positive Individual Phase Apparent Energy (kVAh) (Signed)
7050 kVAh L2 Positive “
7080 kVAh L3 Positive “
