Modbus Offset Register Description
50200 10199 CT2 Integer Integer part of CT2
50201 10200 CT2 Decimal Fractional part of NV_CT2
50225 10224 CT2 Type Select 1=mV or 2=Rogowski CT2s
50299 10298 CT2 Phase Shift Phase Shift X 100 +/-
50300 10299 CT3 Integer Integer part of CT3
50301 10300 CT3 Decimal Fractional part of NV_CT3
50325 10324 CT3 Type Select 1=mV or 2=Rogowski CT3s
50399 10398 CT3 Phase Shift Phase Shift X 100 +/-
PULSE OUTPUT/INPUT REGISTERS
Modbus Offset Register Description
44402 4401
Port 1 output control when
used as an on/off—open/closed
switch
0 = output LOW (closed)
1 = output HIGH (open) [default]
Register 45110 must = 0 to use
45110 5109
Digital Port 1 Configuration
Turns pulses on/off
0 = No pulses, Port may be used as an on/off—
open/closed switch
44001 = System kWh pulses
44008 = System kVARh pulses
44011 = System kVAh pulses
45111 5110 Port 1 pulse output relay type
0 = normally open (HIGH)
1 = normally closed (LOW)
ABSOLUTE MEASUREMENT REGISTERS
Offset refers to a base of 40001.
Modbus Offset Register
Description
* System=sum of three phases
44001 4000 kWh System LSW System Total True Energy LSW (kWh)
44002 4001 kWh System MSW System Total True Energy MSW (kWh)
44003 4002 kW System
System Total True Power (kW). Unsigned absolute
(ABS) value of ABS (kW L1) + ABS (kW L2) + ABS (kW
L3)
