Modbus Offset Register
Description
* System=sum of three phases
44004 4003 kW Demand System Max System Maximum Demand (peak demand).
44005 4004 kW Demand System Now Average Power (kW) for most recent demand window
44006 4005 kW System Max
System Maximum Instantaneous kW
(Highest kW sample measured)
44007 4006 kW System Min
System Minimum Instantaneous kW
(Lowest kW sample measured)
44008 4007 kVARh System LSW System Total Reactive Energy LSW (kVARh)
44009 4008 kVARh System MSW System Total Reactive Energy MSW (kVARh)
44010 4009 kVAR System
System Total Reactive Power (kVAR). Unsigned
absolute (ABS) value of ABS (kVAR L1) + ABS (kVAR L2)
+ ABS (kVAR L3)
44011 4010 kVAh System LSW System Total Apparent Energy LSW (kVAh)
44012 4011 kVAh System MSW System Total Apparent Energy MSW (kVAh)
44013 4012 kVA System
System Total Apparent Power (kVA). Unsigned WYE =
(kVA L1) + (kVA L2) + (kVA L3) Delta = SQRT (kW
system ^2 + kVAR system ^2)
44014 4013 Displacement PF System
System Displacement Power Factor (PF). Register is
100x actual value.
44015 4014 Apparent PF System
System Apparent Power Factor (PF). Register is 100x
actual value.
44016 4015 Amps System Avg Average of all phases.
44017 4016 Volts Line to Line Avg Voltage Line to line (Volts) Average.
44018 4017 Volts Line to Neutral Avg Voltage Line to neutral (volts) Average.
44019 4018 Volts L1 to L2 Individual Phase to Phase Voltages
44020 4019 Volts L2 to L3 “
44021 4020 Volts L1 to L3 “
44022 4021 Line Frequency Line Frequency (Hz)
