83
PULSE OUTPUT/INPUT OBJECTS
Object
Identifier Name Description
13020
Port 1 output control when
used as an on/off—open/closed
switch
0 = output LOW (closed) 1 = output HIGH (open) [default]
Object 13100 present value must = 0 to use
13100
Digital Port 1 Configuration
Turns pulses on/off
0 = No pulses, Port may be used as an on/off—
open/closed switch
44001 = System kWh pulses
44008 = System kVARh pulses
44011 = System kVAh pulses
13110 Port 1 pulse output relay type
0 = normally open (HIGH)
1 = normally closed (LOW)
ABSOLUTE/NET VALUE MEASUREMENT OBJECTS
System=sum of three phases.
Object
Identifier Name
Description
* System=sum of three phases
1000 kW Demand System Maximum System Maximum Demand (peak demand) (Unsigned/Absolute)
1010 kW Demand System Now Average Power (kW) for most recent demand window
(Unsigned/Absolute)
1020 kW Demand System Minimum Min Average power window (kW) (Unsigned/Absolute)
1030 kW System System True Power (kW). Unsigned absolute (ABS) value of
ABS (kW L1) + ABS (kW L2) + ABS (kW L3)
1031 kW System Net System Power (kW) Signed net value of (kW L1) + (kW L2) + (kW L3)
1060 kW System Average Equals kWh System / (Time Since Reset /3600 seconds/Hr)
(resettable)
1100 kW System Maximum System Highest Instantaneous Draw Since Reset (kW)
1130 kW System Minimum System Lowest Instantaneous Draw Since Reset (kW, resettable)
1160 kW L1 Individual Phase True Power (kW) (Signed)
1190 kW L2 “
