82
Object
Identifier Name Description
12040 Demand Window Demand window size in minutes; default is 15 min
12050 Volts Multiplier Multiply volts values by this scalar. For use with stepdown
transformer. Affects all parameters that use volts.
12061 CT1 Amps Multiplier Multiply CT1 amps values by this scalar. For use with stepdown
transformer. Affects all parameters that use amps.
12062 CT2 Amps Multiplier Multiply CT2 amps values by this scalar. For use with stepdown
transformer. Affects all parameters that use amps.
12063 CT3 Amps Multiplier Multiply CT3 amps values by this scalar. For use with stepdown
transformer. Affects all parameters that use amps.
12070 Com Settings Baud: 900=9600, 1900=19200, 3800=38400, 5700=57600,
7600=76800, 11500=115200
Parity: Add 00 = NO, Add 10 = ODD, Add 20 = EVEN
Stop bit: Add 0 = 1 (UART does not permit 0 stop bits), Add 1 = 1, Add
2 = 2
E.g., 901 = 9600 baud, no parity, 1 stop bit
12080 Service Type A value of 1 configures the meter for Delta.
A value of 0 configures the meter for Wye.
12090 Line Frequency Line frequency setting for metering. 50 = 50 Hz, 60 = 60 Hz
12110 Snap Rog Threshold “Snap to Zero” threshold Rogowski CTs. Register value is:
12120 Snap Volt Threshold “Snap to Zero” threshold for voltage. Register value is 1x:
12130 CT Type All Writes same type for all CTs: 1=MilliVolt, 2=Rogowski
12131 CT1 Type 1=MilliVolt, 2=Rogowski
12132 CT2 Type 1=MilliVolt, 2=Rogowski
12133 CT3 Type 1=MilliVolt, 2=Rogowski
