81
ALL THINGS BACNET
The PS3037 supports writable max_master and max_info_frames properties in the device object for
MS/TP networks. For best network performance, the max_master should be set to the highest MS/TP
MAC address on the network.
The max_info_frames does not need to be changed in most installations.
The device ID property of the BACnet device object is also writable. All device IDs on a BACnet network
must be unique.
METER SPECIFIC OBJECTS
Object
Identifier
Name Description
10080 Hardware ID Hardware revisions
10090 Features New features
10150 PowerScout Element ID Used for ViewPoint to determine which element is being read & total
number of elements available. Element index multiplied by 256 +
number of elements.
CONFIGURATION OBJECTS
Object
Identifier Name Description
10020 Data Acquisition Tick Internal sample count (gets cleared every minute): may be used to
determine if sample read is a newer sample than last read.
10140 Clear Accumulated
Measurements
Writing 1234 to the present value will reset all the accumulator
objects (kWh, kVAh, kVARh)
10190 Communications protocol Used to change between BACnet and Modbus communications
protocols.
12003 CT3 Phase Shift CT3 phase shift (degrees)
12011 CT1 Value CT1 Value
12012 CT2 Value CT2 Value
12013 CT3 Value CT3 Value
12030 CT Pulse Scalar Changes the scaling of the output pulses
