88
APPENDICES
Appendix A—Additional Wiring Diagrams
Typically, the PowerScout can be wired using any one of the previous setups found in the PowerScout
3037 Wiring Diagrams. The following are less frequently used configurations and will assist you in
properly connecting your PowerScout meter for the desired setup. ALL WIRE COLORS ARE U.S.
STANDARD.
W
ARNING! DO NOT EXCEED 600VAC PHASE TO PHASE CAT III.
When complete, close the enclosure cover, if equipped.
Attention: Ne pas dépasser une phase à 600VAC CAT III.
Une fois terminé, fermer le covercle, s’il y en a un.
C
AUTION: THE POWERSCOUT
™
METER SHOULD ONLY BE WIRED BY QUALIFIED
PERSONNEL. HAZARDOUS VOLTAGES EXIST.
A
TTENTION: LE POWERSCOUT ™ ne doit être branché QUE par un personnel qualifié.
TENSIONS DANGEREUSES sont présentEs.
DANGER! THE UNENCLOSED POWERSCOUT BOARD REQUIRES EXTRA CAUTION
WHEN CONNECTING. LIFE THREATENING VOLTAGES EXCEEDING 600 VOLTS MAY
EXIST ON THE BOARD.
THE RISK OF SERIOUS INJURY OR DEATH SHOULD NOT BE
UNDERESTIMATED.
D
ANGER! LA PLAQUETTE DE CIRCUITS IMPRIMES SANS COUVERCLE EXIGE UN
REDOUBLEMENT DE PRUDENCE QUAND ON FAIT LA CONNEXION. LES TENSIONS
DEPASSANT 600 VOLTS PEUVENT EXISTER SUR LA PLAQUETTE ET PEUVENT METTRE
LA VIE EN DANGER.
LE RISQUE DE BLESSURES GRAVES OU DE MORT NE DOIT PAS
ETRE SOUS-ESTIME.
