84
Object
Identifier Name
Description
* System=sum of three phases
1220 kW L3 “
2000 kWh System Total System True Energy (kWh) (Unsigned/Absolute)
2021 kWh System Total Net System True Energy (kWh) (Net)
2051 kWh L1 Net Individual Phase True Energy (kWh) (Net)
2081 kWh L2 Net “
2111 kWh L3 Net “
3000 Volts Line to Line Average Voltage Line to line Average
3010 Volts Line to Neutral Average Voltage Line to neutral Average
3020 Volts L1 to L2 Individual Phase to Phase Voltages
3030 Volts L2 to L3 “
3040 Volts L1 to L3 “
3050 Volts L1 to Neutral Individual Phase to Neutral Voltages (V)
3060 Volts L2 to Neutral “
3070 Volts L3 to Neutral “
4010 Amps System Average Average of all phases.
4020 Amps L1 Individual Phase Currents (A)
4030 Amps L2 “
4040 Amps L3 “
5000 kVAR System System Total Reactive Power (kVAR). Unsigned absolute (ABS) value
of ABS (kVAR L1) + ABS (kVAR L2) + ABS (kVAR L3)
5001 kVAR System Net System Total Reactive Power (kVAR). Signed net value of (kVAR L1)
+ (kVAR L2) + (kVAR L3)
5030 kVAR L1 Individual Phase Reactive Energy LSW (kVARh) (Signed)
5060 kVAR L2 “
