85
Object
Identifier Name
Description
* System=sum of three phases
5090 kVAR L3 “
5120 kVAR Demand System Max System Maximum Instantaneous kVAR Demand (kVA, resettable). It
displays the default value after a CAM until 1 demand window
elapses. After a power cycle or CPU reset the value is not reset but
it does not update again until 1 demand window elapses.
(Unsigned/Absolute)
5130 kVAR Demand System Now Average kVAR demand for most recent window (resettable).
Displays the default value after a CAM or reset, or power cycle.
Updates every min thereafter. True demand value takes a demand
period to get to actual value. (Unsigned/Absolute)
6010 kVARh System System Total Reactive Energy (Unsigned/Absolute)
7000 kVAh System Total System Total Apparent Energy (Unsigned/Absolute)
8000 kVA System System Total Apparent Power (kVA). Unsigned absolute (ABS) value
of ABS (kVA L1) + ABS (kVA L2) + ABS (kVA L3)
8001 kVA System Net System Net Apparent Power (kVA). Signed net value of (kVA L1) +
(kVA L2) + (kVA L3)
8010 kVA L1 Individual Phase Apparent Powers (kVA) (signed)
8020 kVA L2 “Sign is set to the sign of the kW
8030 kVA L3 “
8040 kVA Demand System Max System Maximum Instantaneous kVA Demand (kVA, resettable). It
displays the default value after a CAM until 1 demand window
elapses. After a power cycle or CPU reset the value is not reset but
it does not update again until 1 demand window elapses.
(Unsigned/Absolute)
8050 kVA Demand System Now Average kVA for most recent demand window (resettable). Displays
the default value after a CAM or reset, or power cycle. Updates
every min thereafter. True demand value takes a demand period to
get to actual value. (Unsigned/Absolute)
9000 Displacement PF System System Total Power Factor (PF) (Signed)
9030 Apparent PF System System Total Power Factor (PF) (Signed)
9060 Displacement PF L1 Individual Phase displacement Power Factor (PF)
9090 Displacement PF L2 “
