Address Units ≤ 100A 101 – 400A 401 – 800A 801 – 1600A 1601 – 32,000A
40014 aPF L2 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5
40015 aPF L3 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5 3.0518exp-5
40016 VOLTS L1-L2 0.03125 0.03125 0.03125 0.03125 0.03125
40017 VOLTS L2-L3 0.03125 0.03125 0.03125 0.03125 0.03125
40018 VOLTS L3-L1 0.03125 0.03125 0.03125 0.03125 0.03125
40019 VOLTS L1-N 0.015625 0.015625 0.015625 0.015625 0.015625
40020 VOLTS L2- N 0.015625 0.015625 0.015625 0.015625 0.015625
40021 VOLTS L3- N 0.015625 0.015625 0.015625 0.015625 0.015625
40022 AMPS L1 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40023 AMPS L2 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40024 AMPS L3 3.9063exp-3 0.015625 0.03125 0.0625 0.125
40025 kW 0.004 0.016 0.032 0.064 0.128
40026 kW 0.004 0.016 0.032 0.064 0.128
40027 kW 0.004 0.016 0.032 0.064 0.128
Table D-3: Veris Multipliers for Integer Registers 40001-40027
Per the Veris implementation, to obtain true engineering units, the values returned from the registers in
Table G-2 must be multiplied by the scaling values listed in Table G-3.
For example, if the PowerScout has 100A CTs connected to it, the system reactive power (kVAR) is
calculated by:
 Read register 40004
 Multiply the value returned from register 40004 by 0.004
