7.3 Sintering Crypton
(Not included with all units, see section 4.6, Scope of delivery, page 15.)
Fig. 14: Crypton components.
The Crypton sintering set consists of the following components:
1. Door for Crypton sintering
2. High-performance ceramic bottom plate
3. High-performance ceramic sintering bowl
4. High-performance ceramic sintering guard
5. Lid for high-performance ceramic sintering bowl
6. Zirconium oxide beads, Ø 1.25 mm
Fig. 15: Placement of the sintering objects.
1. Fill the sintering bowl with zirconium oxide beads to a level of
between 1.5 and 2 cm. Use only the zirconium oxide beads for
Crypton (REF 53 5567 0112).
2. Place the objects to be sintered on the sintering bowl and
press into the layer of zirconium oxide beads, up to the
preparation line.
NOTE!
The ZrO2 beads are white when new and turn dark
during the Crypton sintering cycle.
Prior to the first Crypton sintering cycle, the base
plate, bowl, lid, guard and the ZrO2 beads must
undergo a Crypton sintering cycle without any
objects present..
Fig. 16: Assembling the sintering bowl and
sintering guard.
3. Place the sintering bowl centrally on the bottom plate.
4. Cover the sintering bowl with the lid and sintering guard.
5. Load the heating program (section 7.7, Programming, page
29) and use the Start/Stop key to start the program.
The lifting plate moves upward and seals the heating
chamber.
The heating program is executed automatically.
