7.4 Exchanging the chamber door
To sinter Cercon, the chamber door must be exchanged first. In addition, the argon supply line of the Crypton
door must be disconnected.
To exchange the chamber door, proceed as follows:
Fig. 17: Unlocking the connector.
1. To disengage the connector of the argon supply line of the
Crypton door, slide the retaining ring of the connector in
the direction of the furnace housing.
Fig. 18: Disconnecting the argon supply
line.
2. Pull out the argon supply line of the
Crypton door from the connector.
NOTE!
If the supply line remains in the connector while
Cercon objects are sintered, argon will escape
from the baseplate of the Crypton door during the
sintering process.
Fig. 19: Unlocking the door.
3. At the bottom of the door there is a guide pin for securing
the door on the door mount.
Fig. 20: Unlocking the door.
4. To unlock the guide pin, pull it down and turn it to the left.
The pin is now unlocked and secured. The furnace door
can now be pulled forward and out from the mount.
