FEEDING TECHNOLOGY
6
3 Operation
3.1 Description of the display
The factory settings of the feeder controller display a standard screen. A different display screen
can be selected in the menu.
Image 2: Display with standard screen
3.2 Description of the keypad
3.3 Description of the menu
Press the button
to display the menu. The user password must be entered. As long as the
password has the default value (default is 0000), then password entry is not necessary.
Scroll through the menu using buttons
and . Use to change to a submenu. In the
submenu use the buttons
and to set values. Press to accept the value and return to
the main menu. Press the button
to return to previous menu section.
NOTE:
The feeder can only be activated to feed parts once the menu is closed.
Press the buttons
or to scroll through menu sections.
BUTTON DESCRIPTION
SELECT THE MENU
SELECT MENU SECTION
SAVE AND LEAVE MENU SECTION
REQUEST FEED PART
DISPLAY PREVIOUS MENU SECTION
DISPLAY NEXT MENU SECTION
LEAVE MENU SECTION WITHOUT SAVING
