How to Put Wizzybug Together
When you are putting Wizzybug together, do not trap your
fingers between the different parts.
Wizzybug has the following parts:
• Body
• Rear Wheel Assembly
• Battery
• Tray (optional, page 46)
REAR WHEEL ASSEMBLY
To attach the rear wheel assembly to the body:
1. Lift up the back of the body using the fabric
handle.
2. Position the rear wheel
assembly with the label facing
away from Wizzybug’s body and
lower the prongs into the two
holes in the rear wheel assembly
beam.
3. Push the spring clip (attached by a
short chain) around the end of the
prong as shown. This attaches the
rear wheel assembly beam to the body.
4. Turn the spring clip sideways under the rear
wheel assembly beam for protection.
Fig. 11 Attaching the Rear Wheel Assembly
