22
1. Clip the harness together and the lap strap
together so that they cannot get caught in
the seating system.
2. Turn the white dial fully anti-clockwise to
unlock the seat.
3. Lift the seat by holding the harness in one
hand and the bottom of the white dial in the
other.
Do not lift the seat using the headrest.
4. Lower the two front corners
of the seat into the two
metal slots above the front
of the battery compartment.
5. Lower the back of the seat
until the pins rest on top of
the coloured metal grids.
6. Use your thumb to squeeze the black seat
release knob towards the top of the white
dial, then lower the seat down so that the pins
line up with the first row of holes for your
child’s seat depth colour. (For example, if your
child’s seat depth setting is yellow, with an
upright back, choose the front row of holes in
the yellow part of the grid).
