Designability WizzyBug - Seating System; Fig. 28 Seat Depth Colour Codes and Slots

30
Seating System
The seating system is designed to be very adjustable. It is
important to adjust the seat so that your child is comfortable and
can use Wizzybug.
We recommend consulting a physiotherapist or occupational
therapist to get advice about the best seating position for your
child.
The seating system on Wizzybug is adjusted without tools. It may
take a little practice, but it is quick and easy to use.
Never adjust the seating position with your child sitting in
the seat, because you or your child could be injured.
SETTING THE SEAT DEPTH
The seat depth is the distance from the back of the seat to the
front of the seat.
There are 5 colour coded positions to give a seat depth from
155mm to 245mm (6.1” and 9.7”).
Orange
Green
Blue
Purple
Yellow
155 mm/
6.1 inches
177.5 mm/
7 inches
200 mm/
7.9 inches
222.5 mm/
8.8 inches
245 mm/
9.7 inches
Fig. 28 Seat Depth Colour Codes and Slots
