Desoutter CVI3 Vision Quick Start User Manual

6159932290_13
23 / 14406/2020
English
At 110 V
I
rms
x
≤ 1 kVA
110
I
rms
≤
I
rms
≤ 8.7 A
110 A
1000
Then we recommend to use a circuit breaker 20A
Curve D.
JVL6-32 Residual Current Circuit Breaker
CVI3 controllers have a JVL6-32 residual current
circuit breaker with over-current protection which
provides protection against earth leakage faults
(30mA), overloads, short-circuits and over-
current in the installation (I=16A. see curve).
The over-current protection of the JVL6-32 uses
“D” tripping characteristics
0.0005
rT gnippi tim te ]ces[
7200
3600
1200
600
300
120
60
30
10
5
2
1
0.5
0.2
0.1
0.05
0.02
0.005
0.01
0.002
0.001
03 04 0551 02
2 3 4 5 6 7 8 9 01
1
acc. to IEC 60898-1
instantaneous tripping
5
4
5
4
3
1
2
N
N
1
2
t
nt
N
N
N
N
4
6
N
3
I = 1.0 I (T=40 °C )
I = 1.35 I : t <1h (T=25 °C )
2.0 I : t = 12- 12 0 s (T=25 °C )
10 I : t < 0.1 s
20 I : t < 0.1 s
conventional non-tripping current
conventional tripping current
type C: 5 I : t > 0.1 s
type D: 10 I : t > 0.1 s
tripping characteristic
acc. to UL 489 / CSA 22.2 No. 235
3
D
C
Multiples of I
n
Figure 1 – Curve C and D
Tools
Any excessive internal temperature of the tool
electric motor is detected by the controller and
the tool motor is 󰀬opped.
The motor can 󰀬art again only after the
temperature has decreased.
Motor temperature limits
handheld tools 60°C
xed tools 100°C
INSTALLATION
● See page 11.
A Quick-stop connection
● Swich o󰀨 the GFI blue interruptor.
● Follow the instructions to wire the shunt.
● Connect the connectors as shown.
B Mounting
● Place the controller in such a way
the GFI blue interruptor can be easily
switched o󰀨.
● Install the controller as shown or use the
optional accessories listed page 9.
C Tool cable connection
● Before connecting the tool, check that its
features do not exceed the operating limits
specied by the manufacturer.
● Refer to the tool user manual at
https://www.desouttertools.com/
resource-centre
Although our tool cables are designed
to work under drastic conditions, we
recommend that you check the following
points for longer service life:
- Bending radii should not be lower
than 10 times the cable diameter
(D-c).
- Friction with the outer sheath
should be restricted (D-b).
- Any direct pull on the cable should
be avoided (D-a).
D Power cord connection
● Only use the cord supplied to connect the
controller to the mains power supply.
● Do not modify the cord or use it for any other
purpose.
