Det-Tronics LS2000 - Installation; System Location Considerations

13 95-87142.2
16.1
(40.8)
10.8
(27.5)
7. 3
(18.5)
7. 0
(17.8)
7. 5
(19.1)
5.0
(12.7)
5.0
(12.7)
A2659
Figure 4—Mounted Dimensions of LS2000 Transmitter
in Inches (cm)
5.0
(12.7)
5.0
(12.7)
14.3
(36.3)
10.8
(27.5)
8.1
(20.6)
7. 9
(20.1)
7. 0
(17.9)
A2660
Figure 5—Mounted Dimensions of LS2000 Receiver
in Inches (cm)
