PARTS IDENTIFICATION
Item Qty Part Number Description
1 1 8555-D264-08 KEYPAD
2 1 8555-D478-0A PCB ASS’Y 750 CONTROLLER (SMT)
3 1 8555-C473-08 REAR PANEL, 750DS
4 1 8555-C253-08 FRONT PANEL
5 2 8555-C213-08 END CAP
6 1 8555-B257-0A BATTERY HOLDER
7 2 8555-B254-08 MOUNTING SPACER
8 4 6680-0004 WASHER, #6 LOCK INT. TOOTH
9 2 6610-2000 JACK SOCKET
10 4 6021-6008 SCREW, #6 X .375 TH SHEET METAL (BLACK)
11 4 6021-2069 SCREW, #6X.50 TH SHEET METAL
12 2 6021-0687 SCREW, #6-32X.312 THMS W/THD-LOCK PATCH
13 1 593GR986 SERIAL TAG
14 2 6680-0052 WASHER, #4 LOCK HELICAL
15 1 8555-B263-08 LABEL: POWER
16 AR 6560-0021 LOCTITE #222
17 1 5930-B126-08 LABEL: ETL FOR 180/200/204/750/758C
¾¾
1 6800-1045 OPTIONAL AC ADAPTER 100-240VAC/12VDC @ 1 AMP
¾¾ NOT SHOWN
8555-M483-O1 Rev A x 750 Owner’s
23
