3300-0192-0M Rev D 01/17 30
PARTS IDENTIFICATION
Base Sub-Assembly
Item Qty. Part Number Description
1 8 0065-B636-08 LOAD CELL SPACER
2 1 3300-0001-0A PCB ASS’Y 855 ANALOG
3 1 3300-0008-0A BASE WELDMENT
4 1 3300-0035-08 WEIGHBRIDGE
5 1 3300-0053-08 COLUMN CLAMP
6 1 3300-0058-18 SOCKET COVER, ICON
7 1 3300-0088-08 ICON COVER PLATE
8 1 3300-0130-1A ICON ANALOG CABLE
9 1 3300-0137-0A CABLE, ICON BATTERY
10 1 3300-0147-1A SUB-ASSY, PLATFORM COVER, ICON
11 1 3300-0266-08 COLUMN CONNECTOR BRACKET, ICON
12 4 6013-0049 NUT 1/4-20 HEX JAM
13 8 6013-0295
NUT #10-32 HEX Z/P
14 4 6013-2008 NUT 1/4-20 CAGE Z/P
15 2 6021-0654 SCW PAN-HEAD,, MACHINE-SCW 06-32X.250
16 4 6021-1033 SCW ROUND-HEAD MACHINE-SCW 10-32X.250
17 4 6021-1417 SCW SOCKET-HD. CAP-SCREW,, 25-20X2.0
18 4 6021-1473 SCW PAN-HEAD,, MACHINE-SCW .25-20X.3125
19 8 6021-1638 SCW HEX/WASHER,, SELF-TAP 10-32X.625, Z/P
20 8 6024-0033 WASHER LOCK HELICAL SP #10 REG Z-PL
21 4 6031-0223
VIBRATION MOUNT, 1/4” – 20 MALE-FEMALE, 1” OD,
1/2” BASE HEIGHT
22 A/R 6560-1061 ADHESIVE LOCTITE 262-21 THREADBLOCKER, HS
23 A/R 6560-1125 ADHESIVE LOCTITE 290 THRD LCKR, WICKING
24 1 6690-0001 LEVEL, "BULLSEYE" TYPE
25 A/R 6710-1021 TAPE 1.88” X 60YDS DUCT ROLL
26 1 593GR986 SERIAL TAG ASSY
27 4 FP-250 LOAD CELL, FLAT PLATE, 250 LBS
To Next Page
