2.4 Fuel System
Engine Description
2.4.1 Fuel system schematic
1 Fuel line from tank to fuel pump
2 Fuel pump
3 Fuel line from fuel pump to easy-change
fuel filter
4 Easy-change fuel filter
5 Fuel line from filter to injection pump
6 Injection pumps
7 Fuel distributor line
8 Injection lines
9 Injection valves
10 Fuel leakage line
11 Fuel overflow pipe
12 Fuel return line to tank
