FUEL
Engine Operation
3.1.2 Filling Oil Bath Air Filter with
Engine Oil
Fill oil cup 1 of the oil bath air cleaner with oil up to
the arrow.
For oil grade and viscosity, see 4.1.
Do not fill the precleaner dust col-
lector (if fitted) with oil.
3.1.3 Adding Fuel
Use only commercial-grade diesel fuel. For fuel
grade, see 4.2. Use summer or winter-grade fuel,
depending on the ambient temperature.
Never fill the tank while the engine
is running. Keep the filler cap area
clean and do not spill fuel.
3.1 Commissioning
3.1.1.3 Initial Engine Oil Fill-Up for
B/FM 1011F Genset Engine
● Fill oil into the oil sump up to the “max.” mark on
the engine dip stick (for oil quantity see 9.1).
● Start up the engine and allow to run at a lower
idling speed for approx. 2 mins.
● Switch off the engine.
● Check the oil level and fill up with oil up to the
upper „max.“ mark.
