Technical Specifications 9.2 Torque Wrench Settings
Location
Preload [Nm] Torquing Load [Nm]
Total [Nm] Remarks
1st
Stage
2nd
Stage
3rd
Stage
1st
Stage
2nd
Stage
3rd
Stage
4th
Stage
Rocker cover 8,5
Rocker arm set screw 21
Air intake manifold 8,5
Exhaust manifold 22
Oil drain plug 55
Injector mounting 21 TORX
Injector line mounting 30
Oil pan (cast iron) 31
Oil pan (sheet metal) 21
21
40
22
