ElectroVap MC
Steam capacity
Electrical installation
The 2 tables under indicate the nominal value of the steam capacity in steam Kg per hour, the
electrical power and the intensity according to the different power supplies.
2 x 230 V 3 x 230 V 3 x 400 V 3 x 415 V 3 x 440 V
Model Capacity Power Current Current Current Current Current
ELMC Kg/V/H Kw Amps Amps Amps Amps Amps
5 5 3.76 16.3 9.6 5.5 5.3 5
8 8 6.02 15.3 8.8 8.5 8
10 10 7.52 32.7 19.1 11 10.6 10
15 15 11.3 28.7 16.5 15.9 15
20 20 15 38.2 22 21.2 20
30 30 22.6 2 x 28.7 33 31.8 30
40 40 30.1 2 x 38.2 2 x 22 2 x 21.2 2 x 20
50 50 37.6 3 x 31.9 2 x 27.5 2 x 26.5 2 x 25
60 60 45.1 3 x 38.2 2 x 33 2 x 31.8 2 x 30
90 90 67.7 3 x 33 3 x 31.8 3 x 30
3 x 460 V 3 x 575 V 3 x 600 V 3 x 690 V
Model Capacity Power Current Current Current Current
ELMC Kg/V/H Kw Amps Amps Amps Amps
5 5 3.76 4.8 3.8 3.7 3.2
8 8 6.02 7.6 6.1 5.9 5.1
10 10 7.52 9.6 7.6 7.3 6.4
15 15 11.3 14.3 11.5 11 9.6
20 20 15 19.1 15.3 14.7 12.7
30 30 22.6 28.7 22.9 22 19.1
40 40 30.1 2 x 19.1 2 x 15.3 2 x 14.7 2 x 12.7
50 50 37.6 2 x 23.9 2 x 19.1 2 x 18.3 2 x 16
60 60 45.1 2 x 28.7 2 x 22.9 2 x 22 2 x 19.1
90 90 67.7 3 x 28.7 3 x 22.9 3 x 22 3 x 19.1
This table enables to determine the steam quantity produced by the ELMC according to the
intensity measured.
Current
2x230 V 3x230 V 3x400 V 3x415 V 3x440 V 3x460 V 3x575 V 3x600 V 3x690 V
Amps Kg/V/H Kg/V/H Kg/V/H Kg/V/H Kg/V/H Kg/V/H Kg/V/H Kg/V/H Kg/V/H
2
0.61 1.05 1,82 1,89 2,00 2,09 2,62 2,73 3,14
5
1.53 2.62 4,55 4,72 5,00 5,23 6,54 6,82 7,85
10
3.06 5.23 9,10 9,44 10,01 10,46 13,08 13,65 15,69
12
3.67 6.28 10,92 11,33 12,01 12,55 15,69 16,37 18,83
15
4.59 7.85 13,65 14,16 15,01 15,69 19,62 20,47 23,54
20
6.12 10.46 18,19 18,88 20,01 20,92 26,15 27,29 31,39
25
7.65 13.08 22,74 23,60 25,02 26,15 32,69 34,11 39,23
27
8.26 14.12 24,56 25,48 27,02 28,25 35,31 36,84 42,37
30
9.18 15.69 27,29 28,32 30,02 31,39 39,23 40,94 47,08
32
9.79 16.74 29,11 30,20 32,02 33,48 41,85 43,67 50,22
37
11.32 19.35 33,66 34,92 37,03 38,71 48,39 50,49 58,06
40
12.24 20.92 36,39 37,75 40,03 41,85 52,31 54,58 62,77
17
