ElectroVap MC
Menu humidifier status
Software assistant
Scroll the menu up or down by pushing on
keys, press the select button to change menu
This Indicates all possible control modes
that can be used:
ON/OFF, 2-3-4 steps, proportional :
(0-10V, 0-20V, 0-20mA, 1-5V, 2-10V,
4-20mA, Sensor (Devatec, 0-10V, 0-5V,
4-20ma), slave regulation.
Diposable cylinder
Tap water (EV), soft water (EA), DI water
(ED), cleanable cylinder, tap water (EV),
soft water (EA), DI water (ED)
This indicates the maximum electrical
power needed for the ELMC.
Total steam production since
the commissionin
Water used: tap water (EV)
Soft water (EA), partial DI water, DI
water (ED), supplying the unit.
Indicate the voltage selected for the
power circuit.
HUMIDIFIER
CONFIGURATION
CONTROL SIGNAL IN
0/10
TOTAL STEAM
PRODUCED HR
WATER QUALITY :
CYLINDER USED :
POWER SUPPLY (V)
MAXIMUM POWER
INSTALL KW
TOTAL HOURS RUN
XX H
Back to the first menu page
TOTAL STEAM PROD.
KG
38
