Devatec ELMC 5 - Menu User Information

36
ElectroVap MC
Menu user information
Software assistant
If regulation :
ON/OFF
2 steps
3 steps
4 steps
In the menu : changement parameter system, if the selection option is yes or no T°C will be at 65°C.
, press the select button
Roll up or down the menu in pushing on keys
to change menu.
MENU
HUMIDIFIER STATUS
STEAM HUMIDIFIER
ELMC XX 3X400
V
STEAM PRODUCED
KG
/H
ACTUAL CURRENT
A
This shows the ELMC model
SET POINT : %
RH MEASURE : %
This indicates the nominal steam
production of the ELMC
Signal of the regulation in case with an
external regulation
Indicates the Rh from the sensor in case
of incorporated proportional + Devatec
sensor
STEAM DEMAND %
This shows the steam demand in the
installation from 20 to 100 %.
OR
WATER TEMP. KEPT
AT 65
°
C
This shows the Amps consumption
TEMP. SENSOR
MISSING
In the menu : changement
parameter, if yes or no has been
selected (draining if long stop).
Display indication
YES NO
DRAINING AFTER XXX HR STOP
If external proportional regulation
ACTUAL CONTROL
SIGNAL Y : XX
V
If proportional regulation incorpored + sensor
Alpha digital status
YES
Display indication
NO
