ineo 4050/4750 2-3
2.1 About this machine
2
2 Overview of This Machine
2.1 About this machine
2.1.1 Name of each part
Front side
*
A USB hub can be connected to the USB Host Port. Only one USB memory device and one Authentication
Unit (IC card type) can be simultaneously connected to a USB hub.
NOTICE
When using a USB hub, use a self-powered hub. If you use a bus-powered hub, the hub could malfunction.
No. Name
1 Control Panel
2 Automatic Document Feeder (ADF)
2-a ADF Feed Cover
2-b Document Guide
2-c Document Feed Tray
2-d Document Output Tray
2-e Document Stopper
3 USB Host Port
*
4 Manual Feed Tray
5 Tray 1
6 Output Tray
7 Data Indicator
3
4
2-e
2 2-c
2-d
5
1
7
6
2-a
2-b
