kEy fEaturES
Key feaTURes
Unpacking The Contents
The following items are included in your DeVilbiss SleepCube system:
1. SleepCube device 4. Carrying case 7. DVD
2. Spare filter pack 5. Air supply tubing
3. AC line cord 6. User manual
If any of the above items are missing, please contact your home care provider.
 If you received a humidier with your SleepCube
system, please refer to the humidier’s instruction
guide for additional information.
DeVilbiss SleepCube Device
(Figures A and B)
1. Keypad/LCD Display (see Figure C)
2. Air Supply Port on Back
3. Air Supply Port on Bottom (for optional humidifier)
4. Air Supply Port Plug
5. Heater Power Connector (for optional humidifier)
6. AC Power Connector
7. DC Power Connector
8. Data Port
9. Power Cord (appropriate to your wall outlet) (not
shown)
10. Air Inlet Filter Opening
11. Connector Cover (not shown)
Keypad (Figure C)
1. On/Off 5. Decrease Value
2. Previous Item 6. Increase Value
3. Next Item 7. Heater Power LED (for
4. Delay optional humidifier)
Ask your home care provider for information about other
DeVilbiss masks, equipment, and accessories.
B
3
5
A
2
8
4
10
7
6
C
1
4
3
2
6
7
5
