DEVISER 92 DS2400Q
Page two(2/3) is used for digital channels test, five
limit items list include of MIN POWER, MAX
POWER, MIN MER, MAX PRE-BER and MAX
POST-BER. The default value of these Limit items
are list as Table 4-4-3. The range of these Limit
items are list as Table 4-4-4. The difference
between MAX POWER and MIN POWER must be
larger than six dB.
Item
Limit
Minimum Power level
50dBμV
Maximum Power level
90dBμV
Minimum MER
32dB
Maximum PRE-BER
1.0E-9
Maximum POST-BER
1.0E-9
Table 4-4-3
