DS2400Q QAM Analyzer Operation Manual
DEVISER 91 DS2400Q
Table 4-4-2.The difference between MAX VIDEO
and MIN VIDEO must be larger than six dB.
Item
Limit
Minimum Video level
60dBμV
Maximum Video level
100dBμV
Minimum △ V/A
10dB
Maximum △ V/A
20dB
Maximum VID
10 dB
Maximum VID DEV
3 dB
Table 4-4-1
Item
Limit
Minimum Video level
30~99dBμV
Maximum Video level
31~120dBμV
Minimum △ V/A
0~19dB
Maximum △ V/A
1~30dB
Maximum VID
1~30 dB
Maximum VID DEV
1~20 dB
Table 4-4-2
