DS2400Q QAM Analyzer Operation Manual
DEVISER 52 DS2400Q
channels. Show as figure 3-8-4.
Figure 3-8-4
SCALE: After selecting the SCALE parameter,
press or to choose one scale from
1dB/, 2dB/, 5dB/ and 10dB/.
CENTER FREQUENCY: After selecting the CENT
parameter, you can input the center frequency by
the character/digit keys.
Note: Any frequency from 5 to 1000MHz can be
input.
