Devolo Magic 2 WiFi 2-1 User Manual

17 Introduction
devolo Magic 2 WiFi
2-1
2.3.1Reading the PLC indicator light
The integrated PLC indicator light (LED) shows the
status for the devolo Magic 2 WiFi
2-1
by illumina-
ting and/or flashing:
LED Flashing be-
haviour
Meaning LED status display
(web interface*)
1 Red LED Lights up for
up to 2 sec.
Start-up process Cannot be disabled
2 Red LED Flashes at in-
tervals of 0.5
sec. (on/off)
Status 1:
The reset of the devolo Magic adapter was
successful. The PLC/reset button has been
pressed and held for 10 seconds.
Status 2:
The devolo Magic adapter (once again) has
the factory default settings. Since the last
reset, no pairing with another devolo Magic
adapter has taken place.
Connect the adapter with another
devolo Magic adapter to create a full-
fledged PLC network as described in
Chapter 2.3 Pairing – Establishing a PLC
connection.
Cannot be disabled

Devolo Magic 2 WiFi 2-1 Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, QPSK
Power plug	Type F
Ethernet LAN	Yes
Damping filter	2 - 80 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
PowerLine standard	HomePlug AC
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit AES, WPA, WPA2, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	2400 Mbit/s
Maximum operating distance	500 m
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	300, 867 Mbit/s
Current	16 A
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power consumption (standby)	3.4 W
Power consumption (typical)	9 W
Antenna type	Internal
Certification	CE
Product color	White
LED indicators	PLC
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Linux operating systems supported	Ubuntu 14.04
Windows operating systems supported	Windows 10, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 x64, Windows 8, Windows 8 Pro, Windows 8 Pro x64, Windows 8.1
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Cables included	LAN (RJ-45)
Quantity per pack	3 pc(s)

Weight and Dimensions

Depth	76 mm
Width	152 mm
Height	40 mm
