Devolo Magic 2 WiFi 2-1 User Manual

Network configuration 50
devolo Magic 2 WiFi
2-1
The Automatically install firmware updates op-
tion allows the adapter to automatically install the
firmware it has found.
The devolo Magic 2 WiFi
2-1
automatically
updates its firmware. The option is enabled
by default.
Download updated firmware
1 If you have downloaded an updated firm-
ware file for the devolo Magic 2 WiFi
2-1
to
your computer, navigate to the System 
Firmware  Update firmware area. Click
Browse … and select the downloaded file.
2 Confirm the update procedure with Update
firmware. After a successful update, the
devolo Magic 2 WiFi
2-1
restarts automatically.
Ensure that the update procedure is not inter-
rupted.
4.7.5Config Sync
Config Sync allows settings to be configured uni-
formly for all devolo Magic devices in the network.
This includes the following settings e.g.:
b WiFi network
b Guest network
b Mesh WiFi
b Time control and time server settings.
In order to switch Config Sync on, activate the
Enable option.
Please note that the WiFi is always switched
on or off for the entire network. Therefore,
stop Config Sync first on a device that you
want to configure or switch separately.

Devolo Magic 2 WiFi 2-1 Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, QPSK
Power plug	Type F
Ethernet LAN	Yes
Damping filter	2 - 80 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
PowerLine standard	HomePlug AC
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit AES, WPA, WPA2, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	2400 Mbit/s
Maximum operating distance	500 m
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	300, 867 Mbit/s
Current	16 A
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power consumption (standby)	3.4 W
Power consumption (typical)	9 W
Antenna type	Internal
Certification	CE
Product color	White
LED indicators	PLC
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Linux operating systems supported	Ubuntu 14.04
Windows operating systems supported	Windows 10, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 x64, Windows 8, Windows 8 Pro, Windows 8 Pro x64, Windows 8.1
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Cables included	LAN (RJ-45)
Quantity per pack	3 pc(s)

Weight and Dimensions

Depth	76 mm
Width	152 mm
Height	40 mm
