Devolo Magic 2 WiFi 2-1 User Manual

51 Appendix
devolo Magic 2 WiFi
2-1
5 Appendix
5.1 Technical specifications
5.2 Bandwidth optimization
To significantly improve the transmission capacity
of the network, we recommend that you comply
with the following "connection rules":
b Plug the devolo Magic 2 WiFi
2-1
directly into a
wall socket. Avoid using power strips. This may
impair the transmission of the PLC signals.
b If there are several sockets in the wall directly
next to each other, they behave like a power
strip. Individual sockets are optimal.
Security 128 Bit AES
Device port 2x RJ45
(Gigabit Ethernet port)
Power consumption Maximum: 12.0 W
Typical: 9.0 W
Stand-by: 3.4 W
Power supply internal
196-250 V AC
50 Hz
Temperature
(Storage/Opera-
ting)
-25°C to 70 °C / 0°C to
40°C
Dimensions
(in mm, without
plug)
152x76x40 (HxWxD)
Ambient conditions 10-90% Humidity,
non-condensing
Certifications CE
Fig. 5: Bandwidth optimization

Devolo Magic 2 WiFi 2-1 Specifications

General

Modulation	64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, QPSK
Power plug	Type F
Ethernet LAN	Yes
Damping filter	2 - 80 MHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
PowerLine standard	HomePlug AC
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	128-bit AES, WPA, WPA2, WPS-PBC, WPS-PIN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Filter characteristics	-22 - -45 dB
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	2400 Mbit/s
Maximum operating distance	500 m
Ethernet LAN interface type	Gigabit Ethernet
WLAN data transfer rates supported	300, 867 Mbit/s
Current	16 A
AC input voltage	196 - 250 V
AC input frequency	50 Hz
Power consumption (standby)	3.4 W
Power consumption (typical)	9 W
Antenna type	Internal
Certification	CE
Product color	White
LED indicators	PLC
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Linux operating systems supported	Ubuntu 14.04
Windows operating systems supported	Windows 10, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 x64, Windows 8, Windows 8 Pro, Windows 8 Pro x64, Windows 8.1
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Cables included	LAN (RJ-45)
Quantity per pack	3 pc(s)

Weight and Dimensions

Depth	76 mm
Width	152 mm
Height	40 mm
