30
ON/OFF SWITCH
1. Remove switch from recoil base and detach leads from
terminals.
2. Using an ohm meter measure the resistance between
terminals1and2withtheswitchintheONposition(|).The
ohm meter should read approximately infinity.
3. Using an ohm meter measure the resistance between
terminals1and2withtheswitchintheOFFposition(O).
The ohm meter should read approximately zero.
4. If either of the tests described here yield a different result
replace the switch.
