76
NOMAD
Use only the supplied AC/DC power supply. Unwrap
the power cord of the power supply and connect it to the
charging cradle, then to an AC electrical outlet (universal
voltage accommodated). The charger will flash red lights
as it initiates, followed by a single green circle that will
illuminate to indicate there is adequate power to the
charging cradle. If the green circle does not illuminate, the
charging cradle is not receiving adequate power and may
need to be sent to a manufacturer authorized service centre for repairs.
Position the charging cradle away from the normal patient environment and ensure the
AC plug remains easily accessible. A plug adapter may be needed to accommodate the
local AC configuration.
Invert one of the handsets and carefully slide it onto the charging cradle (do not
force the handset onto the charging cradle or damage
may result). Expect charge time to be less than five hours.
The handset, charging cradle, and AC power supply may
become warm to the touch while charging.
When the handset is first slid onto the charging
cradle, the first bar will illuminate green for approximately
two seconds to indicate that the cradle and handset are
communicating. If the bars illuminate or flash red, see the troubleshooting guide section
6.2.10. Authorized service
will also be required if no illumination occurs upon sliding the handset onto the charging
cradle.
After illuminating green, the first bar will begin flashing to indicate that charging has
begun. When the first bar turns solid green, the handset is 1/3 charged, and the second
bar will begin flashing green. When the second bar turns solid green, the handset is 2/3
charged, and the third bar will begin flashing green. Once the third bar turns solid green,
the handset is fully charged. Remove the handset from the charging cradle once it is fully
charged.
Receiving Adequate Power
Contact manufacturer
for Service
Handset 1/3 Charged Handset Fully ChargedHandset 2/3 Charged
