Touch Pad Description
Description
These L.E.D.s are on solid when a particular cycle is chosen for operation or programming.
This L.E.D. is part of the 4-digit numeric display and will be on solid during the drying part of a
cycle when the gas valve does not need to be on. The L.E.D. will be blinking when the gas valve
needs to be on. The L.E.D. will not be on solid or blinking (o) if the cycle is stopped, complete,
in cool down, or terminated.
These L.E.D.s are on solid as they are selected during the programming of the dryer controller.
This L.E.D. is on solid when either the stop button is pressed once or the door is opened during
an operating cycle.
Description
This touch pad switch will increment (increase) dry time, cool down time, and drying temperature.
It will also scroll upwards when selecting a dry cycle.
This touch pad switch will decrement (decrease) dry time, cool down time and drying
temperature. It will also scroll downwards when selecting a dry cycle.
This touch pad switch allows the dryer controller to enter the permanent prdgramming mode.
This touch pad switch will select one of the three variable parts of the dry cycle (dry time,
temperature, or cool down) by sequencing through them. Once one ofthe variable parts of the
dry cycle is chosen and changed, this touch pad switch will enter the new (changed) value into
the dry cycle program.
This touch pad switch allows the dryer controller to enter the temporary programming mode.
This touch pad switch will stop the dryer during a dry cycle without clearing the present drying
cycle if pressed once. If pressed and released twice, consecutively, the present dry cycle will be
cleared.
This touch pad switch will start the operation of a dry cycle if pressed and
released once. Pressing and holding this touch pad switch will display the current
temperature of the dryer heat sensor as long as it is held in the depressed
position.
Description
This message is displayed after a dry cycle is complete and the dryer loading door
has been opened or the STOP touch pad key on the dryer controller has been
pressed and released twice.
This message blinks immediately after completion of the dry cycle and continues
to blink until the stop key on the dryer controller touch pad is pressed or the dryer
loading door is opened.
This message is displayed when entering the permanent programming mode.
This message appears while the dryer is in the heating time of a dry cycle.
The decimal point will blink if the output for the gas valve is on, or remain on
constantly if the output for the gas valve is not on. The number represents the
total time left in the dry cycle (includes cool down time).
This message appears when the cool down time of the dry cycle is reached.
The letter “C” represents the cool down (non-heating) part of the dry cycle. The
number(s) after the letter “C” represent(s) the total time remaining in the dry
cycle.
This message appears if there is a dryer fault. The letter “F” indicates a fault and
the number after the “F” represents the specic fault that has occurred. There are
ve dierent faults that can appear (Fl through F5).
Start
Message
LOAd
donE
Prog
.15
C02
F5
