Dexter Laundry T650 - Wiring Harness Part # by Model

Wiring Harness Part # by Model
Key Description T650 T750 T950 T1450 QTY
* Wiring Harness, Door Lock 9627-791- 001 9627-791-005 9627-791-005 9627-791- 005 1
* Wiring Harness,CoinDrop Mech 9627-792-001 9627-792-001 9627-895-001 9627-792-001 1
* Wiring Harness,
Drain,Thermo,DoorSol
9627-796-002 9627-796-002 9627-796-002 9627-796-002 1
* Data Cable 9806-015-001 9806-015-001 9806-015-001 9806-015-003 1
* Wiring Harness P20/P21 9627-793- 001 9627-793-001 9627-793-001 9627-793-001 1
* Wiring Harness P8/P16 9627-794-001 9627-794- 0 01 9627-794-001 9627-794-001 1
* Wiring Harness WaterValve/P19 9627-795-004 9627-795-004 9627-795-004 9627-795-004 1
* Wiring Harness LED PCB 9627-797-001 9627-797-001 9627-797-001 9627-797-001 1
* Wiring Harness P5/pressure 9627-908-010 9627-908-010 9627-908-012 9627-908-014 1
* Wiring Assembly Yel. 32” 8220-064-023 8220-064-023 8220-064-023 8220-064-062 2
* Wiring Assembly Red 7” #36 9631-381-018 9631-381-018 9631-381-018 9631-381-018 3
* Wiring Assembly Blk/Blu 8220-001-231 8220-001-231 8220-001-231 8220-001-231 1
* Wire Assembly BLK. 23” #8 8220-063-029 8220-063-029
* Harness Power Terminal Block 9627-747-003 9627-747-003 9627-747-003 9627-747-003 1
* Wire Yellow Jumper (water valve) 8220-119-002 8220-119-002 1
Cable Assembly, USB 9806-022-001 9806-022-001 9806-022-001 9806-022-001 1
103
Part # 8533-093-001 1/18
