T650 C-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T750 1ph or 3ph 60hz Main (wash & spin) T1 & T2 2.25 2.61
Dexter #9376-319-001 T2 & T3 2.25 2.61
Marathon # T1 & T3 2.25 2.61
T750 C-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T750 1ph or 3ph 60hz Main (wash & spin) T1 & T2 .944 1.097
Dexter #9376-329-001 T2 & T3 .944 1.097
Marathon # T1 & T3 .944 1.097
T950 C-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T950 1ph or 3ph 60hz Main (wash & spin) T1 & T2 .944 1.097
Dexter #9376-329-001 T2 & T3 .944 1.097
Marathon # T1 & T3 .944 1.097
T1450 C-Series Express Washer
Resistance
Motor Winding Wire # Minimum Maximum
T1450 1ph or 3ph 60hz Main (wash & spin) T1 & T2 .435 .505
Dexter #9376-326-001 T2 & T3 .435 .505
Marathon # T1 & T3 .435 .505
NOTE: Resistance values are measured at the stator. Values at the end of the motor wiring
harness may be slightly higher.
Vended Drive Motor Inverter Type
Motor-Winding Resistance Chart
70
Part # 8533-093-001 1/18
